Read MoreAluminium Alloy 3000 series Supplier and Stockist in India
Largest Aluminium Alloy 3003 Stockist in Mumbai, India. ASTM B209 Aluminium 3103 Round Bars Supplier AMS 4006 Aluminium 3105 Sheets Dealer, AMS 4008 Aluminium 3105 Plates Stockist. Reliable Aerospace Grade Aluminium 3000 Series Stockist & Exporter.
Aluminium 3000 Series alloys are manganese-based aluminum alloys renowned for their excellent corrosion resistance, good formability, and moderate strength. These alloys offer exceptional durability in atmospheric and marine environments, making them ideal for aerospace and defense applications where long-term reliability and lightweight performance are critical. Common uses include aircraft panels, aerospace cladding, heat exchangers, and structural components that require a combination of strength, corrosion resistance, and ease of fabrication.
Aluminium Alloy 3000 Series
At Bhansali AeroAlloys, we supply Aluminium 3000 Series in sheets, plates, round bars, and custom forms tailored to aerospace, defense and critical industries requirements. For technical datasheets, pricing, or custom orders, please contact us at sales@bhansaliaeroalloys.com
Specifications For Aluminium Alloy 3000 Series
| Forms | Available in Round Bars, Sheets & Plates, Pipes (Custom Form Available) |
| Sizes | As per requirement |
| Applications | Aerospace Structural Applications, Aircraft Frames, Wings, Fuselage, Fuel Tanks, Armored Vehicles, Missiles, Defense-Grade Parts, etc. |
Aluminium Alloy 3000 Series
| Alloy Designation | UK Specifications | US Specifications | US Federal Specifications | European | Other |
|---|---|---|---|---|---|
| 3003 | A93003 |
AMS 4006 3003-T0 Sheet, plate AMS 4008 3003-H14 Sheet, plate AMS 4067 3003-H14 Seamless tube |
QQ-A-225/2 3003 Cold finished bar QQ-A-250/2 3003 Sheet and plate WW-T-700/2 3003 Seamless tube |
||
| 3103 | BS N3 BS 4 L59 3103-H16/H26 Sheet BS 4 L60 3103-H12/H22 Sheet BS 4 L61 3103-O Temper Sheet |
WS 3.0515 | |||
| 3105 | BS N31 | WS 3.0505 |
Chemical Composition Limits Alloy 3003
| Weight% | Al | Cu | Si | Fe | Mn | Zn | Others |
|---|---|---|---|---|---|---|---|
| Alloy 3003 | Rem | 0.05 - 0.20 | 0.60 max | 0.70 max | 1.0 - 1.5 | 0.10 max |
0.05 each 0.15 total |
Typical Mechanical Properties Alloy 3003
| Material | Condition | Tensile Strength (ksi min) | Yield Strength (ksi min) | Elongation % in 2" 0.064 Sheet | Min 90° Cold Bend Radius for 0.064" Thick |
|---|---|---|---|---|---|
| Alloy 3003-0 Sheet 0.064" thick | 3003-0 | 14-19 | 5 | 25 | 0 |
| Alloy 3003-H12 Sheet 0.064" thick | 3003-H12 | 17-23 | 12 | 6 | 0 |
| Alloy 3003-H14 Sheet 0.064" thick | 3003-H14 | 20-26 | 17 | 5 | 0 |
| 3003-H16 Sheet 0.064" thick | 3003-H16 | 24-30 | 21 | 4 | 1/2 - 1 1/2 T |
| 3003-H18 Sheet 0.064" thick | 3003-H18 | 27 min | 24 | 4 | 1 1/2 - 3T |
Chemical Composition Limits 3103
| Weight% | Al | Si | Fe | Cu | Mn | Mg | Cr | Ti+Zr | Zn | Others |
|---|---|---|---|---|---|---|---|---|---|---|
| Alloy 3103 | Bal | 0.50 max | 0.70 max | 0.10 max | 0.90 / 1.50 | 0.30 max | 0.10 max | 0.10 max | 0.20 max | 0.050 each, 0.15 Total |
Typical Mechanical Properties
| Material | Temper | Tensile Strength (N/mm²) | Elongation on 50mm | ||||
|---|---|---|---|---|---|---|---|
| 0.5 | 0.8 | 1.3 | 2.6 | 3.0 | |||
| Alloy 3103 Sheet | 0 | 90-130 | 20 | 23 | 24 | 24 | 26 |
| Alloy 3103 Sheet | H12 | 120-145 | 5 | 6 | 7 | 9 | 9 |
| Alloy 3103 Sheet | H16 | 160-195 | 2 | 3 | 4 | 4 | 4 |
Chemical Composition Limits 3105
| Weight % | Al | Si | Fe | Cu | Mn | Mg | Cr | Ti | Zn | Others |
|---|---|---|---|---|---|---|---|---|---|---|
| Alloy 3105 | Bal | 0.60 max | 0.70 max | 0.30 max | 0.30 / 0.80 | 0.20 / 0.80 | 0.20 max | 0.10 max | 0.40 max | 0.050 each, 0.15 Total |
Typical Mechanical Properties
| Material | Temper | Tensile Strength (N/mm²) | Yield Strength (N/mm²) | Elongation on 50mm | |||
|---|---|---|---|---|---|---|---|
| 0.5 mm | 0.8 mm | 1.3 mm | 2.6 mm | ||||
| Alloy 3105 Sheet | 0 | 110-155 | - | 16 | 18 | 20 | 20 |
| Alloy 3105 Sheet | H12 | 130-175 | 115 | 2 | 3 | 4 | 5 |
| Alloy 3105 Sheet | H14 | 160-205 | 145 | 2 | 2 | 3 | 4 |
| Alloy 3105 Sheet | H16 | 185-230 | 170 | 1 | 1 | 2 | 3 |
| Alloy 3105 Sheet | H18 | 215 min | 190 | 1 | 1 | 1 | 2 |
